Single workspace-design provides high load frame stiffness and ergonomic working height
Rigid machine frame construction provides superior axial and lateral stiffness and guarantees robust, durable and long-term operation
Double acting (no plunger) actuator in Servo-Quality mounted on upper crosshead
Polished and hard chromium-plated columns
Movable upper crosshead with manual clamping to adjust optimum grip separation in relation to shortest and longest samples, also sample deformation
Long piston stroke for universal testing without changing the crosshead position, even when testing in conditions
Leather bellows over a complete piston rod protect piston rod from dust, dirt and scale
Anti-rotation system for the actuator prevents the natural tendency of the actuator to rotate
Precision tension / compression rated strain gauge load cell mounted between lower grip and base platen
High resolution digital displacement transducer
Servovalve with manifold attached directly on actuator
Machine is supplied with anti-shock pads below the machine that effectively reduce and isolate vibrations, noise, as well as elastic storage decoupling
Supplied with anchors for fixation on laboratories floor
Durable structured coating (or paint)
Bolts for machine lifting
The machine is free-standing on shock absorbers, requiring no special foundations
Ergonomic working height with unchanged height of lower grip allows an easy sample insertion
